Dental Zirconia Block 5 axis cad cam Milling Machine

Driven by 0.01 mm high precision, this milling unit is designed for dental labs, milling centers, and chairside clinics, effectively solving common zirconia-processing issues such as low efficiency, unstable accuracy, and high downtime losses.



Products
Model	T20D
Axis	5
Milling mode	Dry
Milling type	Crown/coping,Bridge,
Max spindle speed	60000 RPM/min
Spindle power	500w
Spindle cooling	Air cooling
Rotation range	Aaxis: ± 360° Baxis：+25°-135°
Number of tool housed	12
Compatible compressed air	＞6pa(No oil and no water)
Loadable workpiece shape	Disk diameter: 98mm
Input Voltage	AC220V ±10%,50/60HZ
External dimensions	420*540*580mm
Weight	50kg only
Control command set	NC code
Brand	ZOTION
Factory Add	Chongqing,China





1. Hydraulic Damping Door – Smooth Operation with Enhanced Safety

The machine features a hydraulic damping mechanism that automatically controls door movement, preventing rigid impact while ensuring dust-proof and noise-reduction performance suitable for dental production environments.

Benefits:

Improved user experience: Smooth, impact-free open/close action with noise ≤65 dB, reducing operator fatigue during multi-shift workflows.

Enhanced machine protection: Avoids door impact leading to spindle or guide-rail misalignment, reducing maintenance costs.

Clean production environment: Sealed design prevents milling dust leakage and maintains restoration cleanliness, meeting dental hygiene standards.

2. Power-Failure Memory – Resume Milling Without Rework

The built-in recovery module records real-time coordinates, tool status, and machining progress. After power restoration, the system automatically resumes from the exact breakpoint without re-calibration or re-programming.

Benefits:

Save 2–4 hours on long-cycle jobs such as multi-unit bridges and implant bridges.

Reduce material waste: Prevent zirconia discs from being scrapped due to repeated milling; material utilization increases to 95%.

Stable production planning: Power interruptions no longer delay delivery schedules.

3. Automatic Calibration – Consistent Accuracy with Minimal Manual Input

Smart sensors monitor tool wear, clamping deviation, and axis accuracy, automatically compensating machining parameters to ensure consistent precision across all units.

Benefits:

Reliable precision: Marginal fit accuracy ≤ 0.01 mm, fully meeting clinical standards.

Lower training cost: Eliminates manual calibration; reduces operator learning time by 50%.

Longer tool life: Adaptive compensation extends diamond-tool lifespan by 40%.

4. 12-Slot Automatic Tool Changer – Continuous Workflow, Higher Throughput

The 12-position ATC supports presetting tools for roughing, finishing, and polishing. Tools are switched automatically based on CAM sequences, requiring no manual intervention.

Benefits:

Minimized downtime: Tool-change time shortened from 3–5 min to 10–15 seconds.

Supports complex processes: Handles φ1–6 mm tools, suitable for zirconia veneers (as thin as 0.5 mm) to implant abutments (up to 25 mm).

30% productivity increase: Ideal for mixed-material and continuous multi-step production

5. 60,000 RPM Spindle + 0.01 mm Precision – High-Speed Milling for Hard, Brittle Zirconia

The high-speed spindle achieves low-stress cutting at 60,000 RPM, perfectly matching zirconia's hard-brittle characteristics. Combined with 5-axis motion, complex geometries can be shaped in a single setup.

Benefits:

High efficiency: Single crown milling time reduced to 8–10 minutes, supporting chairside "same-day restoration."

Superior surface quality: Roughness as low as Ra ≤ 0.8 μm; post-sintering polishing is largely unnecessary.

Complex geometry capability: Ideal for undercuts, deep grooves, and implant abutment taper connections; good-part yield improves by 60%.







If you're interested in this dental milling machine and would like to know its price and additional details, feel free to contact us!

Founded in 2009 in Chongqing, China, we were the first manufacturer in the country to produce CADCAM 5-axis milling machines. Since our establishment, we have obtained medical device quality management system certification, and our commitment to quality has earned us international certifications such as CE, SGS, and ISO13485. Our company holds independent import and export qualifications, and our products are now exported to over 100 countries and regions worldwide, including North America, Europe, the Middle East, and Asia. With a focus on innovation, precision, and reliability, we are proud of our manufacturing capabilities and look forward to the opportunity to collaborate with you!
