dental cad cam 5 Axis Zirconia Dry Milling Machine





Name	dental cad cam 5 Axis Zirconia Dry Milling Machine
Model	C5
Milling   mode	Dry
Millable   material	Zirconia,Wax,PMMA,PEEK
The   size of milling material	98mm,98.5mm,Max   thickness:80mm
Product   type	Crown/coping,   Bridge
65Spindle   power	650w
Speed   of spindel	6000-60000   rotation/min
Spindle   cooling	Air-cooled
X/Y/Z   axis motor	50w   servo motor
A/B   axis motor	50w   servo motor
Rotation   range	A   axis: 360°
	B   axis: +25°-115°
Number   of burs(Tools)  housed	8pcs
The   type of milling burs	Auto   milling burs installation
Tool   change and check	Fully   automatic
Compatible   compressed air	＞6pa
External   dimensions	Length   :468mm
	Weigth   :600mm
	Height   :660mm
Packing   dimension	73*55*84cm
Weight	90kg
G.weight	120kg
Input   Voltage	220V   + -10%,50-60Hz,     +
Control   command set	NC   code
Average   milling time(dental crown)	Zirconia   : 8mins
	Wax   :4mins
	Pmma   :5mins











1. Processing performance
Processing accuracy:
This dental milling machine has ultra-high processing accuracy. When milling dental materials such as zirconia, it can achieve ±0.01mm dimensional error control, thanks to its advanced five-axis linkage technology and high-precision transmission system. The five-axis linkage can process the workpiece from multiple angles, avoiding the interference problems that may occur in traditional three-axis processing, so that dental restorations with complex shapes (such as multi-unit bridges, personalized abutments, etc.) can also be accurately milled to achieve a near-perfect fit and meet the high standards of oral restoration. "For example, when making crowns, the edge fit accuracy is improved by more than 30% compared to traditional machine tools, effectively reducing the gaps that may appear after restoration, and improving the restoration effect and service life. "
Processing efficiency:
"The machine is equipped with a high-performance spindle motor with a speed of up to 60,000 rpm. With the intelligent cutting path optimization algorithm, the processing time of a single workpiece is greatly shortened. Taking the common single crown processing as an example, it only takes 5-8 minutes to use our machine tool, which is about 20%-30% more efficient than similar products on the market.
2. Tool system
Tool compatibility:
"Our dental milling machine tool has a wide range of tool compatibility and can adapt to most standard dental milling tools on the market. Whether it is a ball-end tool, flat-bottom tool or taper tool with a diameter of 1mm-6mm, it can be easily installed and used. This provides great convenience for customers. They don't need to worry about tool procurement restrictions. They can flexibly choose tools of different brands and models according to their own processing needs and cost budgets."
"The machine tool is equipped with an automatic tool changing system, which takes only 3-5 seconds to change tools. It can quickly switch different tools for various processes (roughing, finishing, etc.).
Tool life and wear:
"The spindle system of the machine tool adopts advanced dynamic balancing technology and high-precision tool holder interface, which effectively reduces the vibration of the tool during high-speed rotation and extends the service life of the tool. According to actual tests, under normal processing conditions, the life of commonly used dental milling tools using our machine tools can be extended by about 30% - 50% compared to using them on ordinary machine tools, reducing customers' tool replacement costs. "
"At the same time, the machine tool's built-in intelligent tool monitoring system can monitor the wear of the tool in real time. When the tool wear reaches the set threshold, the system will promptly issue an alarm to remind the tool to be replaced, avoiding the problem of reduced processing quality due to excessive tool wear. "

3. Operation and Programming

Operation convenience:

"The machine tool is equipped with a user-friendly operation interface and an intuitive touch screen design. The operation interface is simple and easy to use. Even staff without deep programming and machine tool operation experience can quickly master the basic operation methods of the machine tool and perform daily processing tasks after simple training (the training time is generally no more than 2 days). "

"At the same time, the machine tool has one-touch start, pause, emergency stop and other function buttons, which are convenient for operators to perform necessary operations at any time during the processing process to ensure safe and smooth processing. "
Programming flexibility:
"It supports multiple programming methods. It can use traditional G code programming to meet the precise programming needs of professional programmers, and also provides a graphical programming interface. Through simple graphics drawing, parameter setting and other operations, it can automatically generate processing codes, which is convenient and fast. In addition, the machine tool can also directly import processing files generated by common CAD/CAM software (such as .dxf, .stl formats, etc.) "







Zotion is a manufacturer specializing in the development and production of dental equipment, dental sintering furnaces and dental consumables. It has 15 years of production experience. The factory has a professional R&D team with superb skills, passion and creativity, dedicated to the R&D and production of advanced CAD CAM 5-axis zirconia dry grinding machines.

The factory uses the most advanced technology and the most advanced production equipment for

manufacturing to ensure the quality of each piece of equipment. The factory has rich production experience and a complete quality management system, able to meet customers' individual needs and provide appropriate technical solutions and the highest quality services.
