Zirconia Dental Sintering Furnace
The Zirconia Dental Sintering Furnace, it only takes 25 minutes to complete the sintering process, provides stable high temperature control, makes the sintering process uniform and high quality results (maximum temperature can reach 1650°C), touch screen control, easy to operate. The furnace volume is 1 liter, and 40 units of teeth can be put into the sintering tray, temperature accuracy: +1°C
- Product Introduction
Products Description
The ZOTION F1 Zirconia Dental Sintering Furnace is a fast sintering equipment developed for CAD/CAM zirconia restoration workflows in dental laboratories.
Compared with conventional sintering cycles, the F1 shortens the standard zirconia sintering process to around 25 minutes. The furnace reaches a maximum temperature of 1650°C with temperature control accuracy of ±1°C.
The 1L furnace chamber supports batch processing of up to 40 dental units, including crowns, multi-unit bridges, and veneers. The equipment uses silicon-molybdenum heating elements and a closed-loop PID temperature control system to maintain stable heating performance during repeated sintering cycles.
The F1 furnace is available with CE certification and supports OEM/ODM services, including logo customization and sintering program configuration according to customer requirements.
|
Product model
|
F1
|
|||
|
Rated voltage
|
AC:220;50/60HZ
|
|||
|
maximum temperature
|
1650
|
|||
|
Furnace volume
|
1 liter
|
|||
|
Furnace size
|
42*30*60cm
|
|||
|
Furnace weight
|
35kg
|
|||
|
Temp Accuracy
|
±1℃
|
|||
|
Temperature Control
|
Touch Screen Control System
|
|||
|
Facroty ADD
|
Chongqing,China
|
|||
|
OEM
|
Support
|
|||
Core Technical Features
Fast Heating Performance and Uniform Temperature Control
The F1 uses high-temperature silicon-molybdenum heating elements combined with a three-dimensional heating structure inside the chamber.
The heating rate can reach up to 150°C/min. The furnace structure helps improve heat distribution inside the chamber and reduces temperature differences between different positions during the sintering process.
Stable thermal conditions are important for zirconia densification, shrinkage control, and color consistency after sintering.
Intelligent Operation System
The F1 is equipped with a flat-panel touchscreen interface.
The operation system includes:
One-touch program selection
Start and stop control
Real-time temperature curve display
Remaining time display
Automatic shutdown after program completion
The furnace includes 20 preset sintering programs covering commonly used zirconia materials. Users can also adjust heating rates and holding times according to different material requirements.
Batch Production Capacity
With a 1L sintering chamber, the F1 can accommodate up to 40 dental units in one cycle.
The chamber capacity is suitable for dental laboratories handling daily production of:
Single crowns
Multiple-unit bridges
Veneers
Full-contour zirconia restorations
The batch capacity helps laboratories arrange production schedules more efficiently.
Manufacturing Experience and Service Support
ZOTION has more than 17 years of experience in dental equipment R&D and manufacturing. Our products have been supplied to dental laboratories and distributors in more than 120 countries.
The F1 furnace undergoes factory testing procedures, including temperature calibration and operational inspection before shipment.
Technical support includes:
Remote operation guidance
Installation assistance
Sintering program support
Maintenance guidance
factory
Cover Area
years experience
Exported Countries
Customer Services
Products certificates
customer feedback
FAQ:
1. How long does the F1 zirconia sintering furnace take for a standard sintering cycle?
The F1 can complete a fast zirconia sintering cycle in around 25 minutes, depending on the zirconia material and selected program.
2. How many zirconia restorations can be placed in one cycle?
The 1L chamber can hold up to 40 dental units. The actual loading capacity may vary depending on restoration size and tray arrangement.
3. Can the F1 work with different zirconia brands?
Yes. The furnace supports commonly used zirconia materials. Users can select preset programs or adjust parameters according to the zirconia manufacturer's recommended sintering curve.
4. Is the furnace difficult to operate?
The touchscreen interface simplifies daily operation. Operators can select programs, monitor temperature curves, and manage sintering cycles through the display panel.
5. Can the sintering program be customized?
Yes.
