Zirconia Dental Milling Machine Cad Cam 5 Axis Cnc Dental Milling System
The Zirconia Dental Milling Machine Cad Cam 5 Axis Cnc Dental Milling System is capable of milling materials such as zirconia, wax, PMMA and PEEK, and its high-quality spindle and servo motors ensure excellent stability and efficiency. The machine has a spindle speed of 6000 RPM and a 360° rotating A-axis. It is equipped with a tool magazine that can accommodate 8 to 14 tools, which can automatically manage and install tools. The Zotion 5-axis is rated at approximately 650W, which enables fast milling speeds, and the maximum operating speed of the XYZ axis is 6000 mm/min, and the maximum operating speed of the Z axis is 4000 mm/min. High-precision multi-function fixtures and remote control improve usability, while the machine helps save milling material, allowing 30% more dentures to be produced per zirconia block.
- Product Introduction
Products Description
This is a high-end 5-axis CAD/CAM milling system designed for digital dental laboratories and clinical applications. Built around the core principles of precision, efficiency, and full-scenario adaptability, it enables one-stop processing of materials such as zirconia, PMMA, and wax, covering a full range of restorations from single crowns to veneers.
Products parameter
Products Details
Products advantages
True 5-Axis Simultaneous Machining
Single clamping. Full-angle precision.
Equipped with a dual-axis structure (A-axis ±360°, B-axis 25°–115°), the system allows tools to approach the workpiece from virtually any angle.
Complex geometries - including multi-surface structures, undercuts, and curved surfaces - can be completed in a single clamping, eliminating errors caused by repeated repositioning in traditional 3- or 4-axis systems.
This results in significantly improved marginal integrity and fit accuracy, with edge gaps controlled within ±0.01 mm, achieving up to 30% higher precision compared to conventional machines.
High-Efficiency Machining
High-speed spindle + intelligent toolpath optimization
Equipped with a high-speed spindle up to 60,000 rpm and advanced toolpath algorithms, the system delivers fast and efficient milling.
A single zirconia crown can be completed in 5–8 minutes, improving efficiency by 20–30% compared to similar equipment.
Supports dry milling, with a sealed anti-dust design to reduce equipment wear.
Compatible with an automatic tool changer (up to 14 tools), enabling continuous multi-material and multi-process machining without manual intervention.
Ideal for both high-volume production and chairside immediate restoration workflows.
Strong Compatibility
Open system for seamless digital workflow
Built on an open architecture, the system directly reads standard NC files, eliminating the need for format conversion and enabling a smooth design-to-production workflow.
Compatible with most zirconia discs and consumables on the market, allowing laboratories to continue using their existing material systems without additional investment.
Stability and Durability
Precision engineering for long-term performance
Equipped with high-precision linear guides and a direct drive system, the machine ensures minimal vibration even under continuous heavy-load operation.
Integrated features include:
Automatic tool calibration
Tool breakage detection
Multi-dimensional safety monitoring (air pressure, water temperature, axis overload)
The system automatically stops and alerts in case of abnormalities, reducing scrap rates and equipment risks.
A dust-proof sealed structure and maintenance-friendly design further ensure reliable 24/7 operation.
Cost Efficiency
Higher material utilization, smarter operation
The patented angled clamping structure, combined with a force-feedback system, enables precise clamping control and improves material utilization by up to 30%.
Supports remote monitoring and parameter control, with multiple preset machining programs for quick deployment.
Technicians can adjust parameters remotely, reducing on-site intervention and significantly improving overall laboratory efficiency.
factory
Cover Area
years experience
Exported Countries
Customer Services
Products certificates
customer feedback
Hot Tags: Zirconia Dental Milling Machine Cad Cam 5 Axis Cnc Dental Milling System, China, suppliers, manufacturers, factory, customized
