5 Axis Milling Machine
5 Axis Milling Machine,which is a dry and high precision milling machine for dental lab and milling center. It can mill zirconia,wax,pmma,peek. C5 uses high quality spindle and servo motor,which ensures the stability of the milling machine.
- Product Introduction
Products Description
Products parameter
|
The size of the milling material
|
98mm,98.5mm and the max thickness is 80mm
|
|
The max speed of XYZ axis
|
Z axis 4000mm/min XY axis 6000mm/min
|
|
The max speed of the spindle
|
6000-60000 rotation/min
|
|
The angle of the axis
|
Aaxis +-360°B axis :25-115°
|
|
The type of milling burs
|
Auto milling burs installation
|
|
The amount of milling burs
|
DiameterΦ 4*56mm
|
|
Controlling instruction set
|
NC code
|
|
Interface
|
USB 2.0.100M Internet access
|
|
Voltage
|
220V +-10%,50/60 Hertz
|
|
Power Consumption
|
Noise-pollution level
|
|
Noise-Pollution level
|
Standby model : under 45 decibel milling model: under 70 decibel The data was tested by UT353, the level of the noise varies when different material is used.
|
|
Install conditions
|
Indoor installation altitude below 2000m,temperature :5-40 degree Celsius
|
|
The size of the machine
|
470*560*650mm
|
|
Weight
|
90kg
|
Products advantages
1, 100°patent design holder: help save 30% materials (5-6 more teeth) than usual 98.5mm holder.
2, closed tool magazine: keep the burs clean and steady, extend the burs using time
3, Built-in computer: input STL file through USB or internet can mill, no need extra computer for the machine
4, Stable structure of the machine: ensure the accuracy and stability of the milling, no need calibration after use
5, Stainless steel working chamber: easy to clean
6, Precision tool setting instrument: ensure milling accuracy
