Open System Cad Cam 5 axis Dental Milling Machine



The Open System Cad Cam 5 axis Dental Milling Machine is a high-precision, high-performance zirconia crystal product grinding and cutting tool with three linear axes (Y, Z, X) and two rotary axes (A and B) with independent five-axis linkage. It uses solid carbide tools to perform high-speed cutting of dry materials such as pre-sintered zirconia (ZrO²), PMMA, wax, composites, etc., providing excellent performance and accuracy in dental applications.





Technical Data:



Specification	Description
Weight	90(kg)
Travel	X Axis：200mm Y Axis：110mm Z Axis：110mm A Axis: ±360° B Axis：+25°-115°
Air pressure	＞6pa(no oil and water)
Maximum spindle speed	60000rpm
Power supply max	max.650W,50-60Hz,220ACV
Current	50-60Hz
Ambient temperature	15-35℃
Machinable materials	Zirconia, wax, PMMA,peek
Closed tool magazine	automatic tool change (14 tool holders), automatic length measurement and breakage detection









Timely Bus: The CPU and 5-axis are connected bilaterally, unlike the traditional systems which use a unilateral connection.

Fully Automatic Tool Magazine: The traditional tool magazine is external, which causes dust to stick to the tool, reducing accuracy and shortening tool life. (This feature is available in the AG market.)

Precision Harmonic Reducer: It uses a precision harmonic reducer for high accuracy, compared to the traditional RV reducer.

Japanese THK Guide Screw: The guide screw is made by THK, the world's leading brand, ensuring stability.

Precision Tool Setter: A high-precision tool setter ensures accurate tool positioning.

Active Dust-proof Technology: Zirconium powder is prevented from entering the machine, extending its service life.

Stable Structure: With 15 years of technological development, the machine has a very stable structure, ensuring that the axes maintain their working points without shifting.

Integrated CNC System: The machine comes with an integrated CNC computer and touch screen, eliminating the need for an external computer. Many devices on the market require external computers.

Dual USB and Network Ports: Data is imported through dual USB and network cable ports.

100-Degree Patented Fixture: The 100-degree fixture allows for a 30% material savings compared to traditional 98mm zirconium blocks, maximizing zirconium block utilization.

Warning Light Setup: Real-time machine status is displayed through a warning light system.

One-Button Spindle Homing: The spindle homing function is activated with a single button, and the machine's working cavity is easy to clean and maintain.

Air Compressor: The air compressor operates at 0.7 MPa.





Zotion was founded in 2009 and has 15 years of production experience. The company primarily manufactures dental milling machines, dental zirconia, dental sintering furnaces, and other related products, all of which are CE and ISO certified. Zotion boasts a complete production line and advanced manufacturing equipment, including 5-axis machining centers, high-speed milling machines, CNC lathes, and more.

The company places a strong emphasis on research and development, with a dedicated, high-quality R&D team focused on technological innovation. Each machine undergoes rigorous quality inspections and optimization debugging to ensure stable and reliable product quality.

In addition, Zotion offers a comprehensive pre-sales, sales, and after-sales service system, providing customers with customized solutions to help them quickly enter the market and achieve success.
