Dental Milling Machine Titanium Premill Abutment 5 axis wet milling machine



Dental Milling Machine Titanium Premill Abutment 5 axis wet milling machine is a high-precision device for processing dental implant abutments. The milling machine uses advanced CAD/CAM technology and can process a variety of titanium alloy materials. It can perform high-precision and high-efficiency processing.

Product Features
High-precision processing:
Equipped with a high-performance spindle and precision control system, the processing accuracy reaches the micron level.
1. High-performance spindle
High-speed and stable: The high-performance spindle can provide high speed (6000-60,000 RPM), and the tool cutting force is evenly distributed during processing.
Low vibration: The spindle design can reduce vibration and noise. When processing hard materials such as titanium alloy and PMMA, the tool can cut stably, improve processing accuracy and surface quality.
High torque: The processing of titanium alloy premilling abutments requires high torque output, and the spindle can provide sufficient cutting force at low speed.
2. Precision control system
High-resolution encoder: The precision control system is equipped with a high-resolution encoder, which can accurately control the movement of each axis. Through the precise feedback system, the accurate position of the tool can be adjusted and maintained in real time.
Closed-loop control system: The closed-loop system can monitor the motion state of each axis of the machine in real time, and each tiny displacement is corrected in real time to avoid error accumulation.
Stable stepper and servo motors: The stepper and servo motors used to drive each axis can accurately control the tool path and reduce dynamic errors. Even complex 5-axis linkage processing can be completed with high precision.
3. Micron-level processing accuracy
Processing accuracy: The processing accuracy can reach ±2μm
4. Micron-level accuracy of specific parameters
Positioning accuracy: The positioning accuracy is 0.001 mm (i.e. 2 μm) in the X, Y, and Z axes.
Repeatability: The repeatability is around 0.0005 mm (i.e. 0.5 μm), ensuring stability during multiple processing.
Inter-axis accuracy: The coordination accuracy between each axis can usually reach 0.001 mm, and there will be no errors in the processing of complex shapes.
Multi-axis linkage:
Usually equipped with a 5-axis or more linkage system, providing comprehensive processing freedom.
It can complete the entire process from roughing to finishing, and realize the personalized customization of the base.
Compatibility:
Compatible with mainstream CAD/CAM software systems, supporting the input of multiple design file formats. (STL, CNC G-code)
Intelligent operation:
Equipped with a friendly user interface and automation functions to simplify the operation process.
Provide real-time monitoring and diagnosis functions to ensure the safety and stability of the processing process.





products
Milling materials	Glass,Ceramic,,Tatinum,premill abutment,Metal disc ,PMMA,Peek,Wax
Axis number	4 Axis and 5 axis for choice
Xyz axis max running speed	Z axis:4000 mm/minXy axis: 6000 mm/min
4 Axis and 5 axis for choice	4 Axis and 5 axis for choice
Spindle RPM	6000-60000 ratotation/min
Rotary axis stroke	A axis +-360 °, B axis +30° (for 5 axis milling machine)
Cooling type	Water Cooling
Tool magazine type	Automatic
Tool numbers	14
Tool size	Shank diameter 4*56 mm
Control code	NC code
Program interface	USB 2.0 ,100M network port
Power requirement	AC220v +-10%,50/60 Hz
Power consumption	650w
Working decibel	<45 decibels in standby:, < 70 decibels when running,The data was tested by UT353,the level of the noise varies when different materialis used
Net Weight	105 kg
Size	WLH 490mm*620mm*625mm

Cooling system: built-in coolant system to reduce the heat generated during processing











Factory scale
We have a modern production base covering an area of ​​more than 2,500 square meters, equipped with the most advanced CNC processing equipment and automated assembly lines. Our factory includes not only a production workshop, but also a research and development center and a quality inspection laboratory to ensure the high quality and continuous innovation of our products.

Production capacity
Our factory has an annual output of more than 2,000 dental milling machines, which can meet the needs of the global market. We also support customized production to meet the special needs of different customers.

Quality control
We strictly follow ISO 13485 and CE certification standards, and carry out strict quality control in every link from raw material procurement to production and processing. We use advanced testing equipment to fully test each device to ensure its performance and reliability.

R&D Innovation
The company has a research and development team composed of senior engineers and technical experts, and invests a lot of resources every year in the research and development of new technologies. We are committed to continuous improvement and innovation to meet market needs and customer expectations.

Customer Service
We provide a full range of customer services, including:

Pre-sales consultation: Provide professional product and technical consultation.

Installation and training: Professional team for equipment installation and operation training.

After-sales support: 24/7 all-weather technical support, quick response to customer service needs.
